F04 — Тормоз задний
Позиций в узле: 26. Выделите строку в таблице или точку на схеме.
| № поз. | Артикул | Наименование | Кол-во | Примечание | |
|---|---|---|---|---|---|
| 1 | TSF0224080 | BUTTON HEAD SOCKET SCREW M6X10 | 1 | В каталоге также: SOCKET HEAD SCREW M6x16 BLACK (LOCKTITE) | |
| 2 | T0602FKE0010N | SPEED SENSOR FRONT WHEEL_M104 | 1 | ||
| 3 | T2501AKW0021N | WET ABS UNIT_J1 DUAL CHANNEL | 1 | ||
| 4 | T25000KW0010N | REAR RESERVOIR HOSE CLIP | 2 | ||
| 5 | T1901JKW0020N | BANJO BOLT KIT | 3 | ||
| 6 | MF01920001500 | A02-SPLIT PIN 2 x 16 IS:549 | 1 | ||
| 7 | T2501HJ30050N | HOSE, ABS TO REAR MASTER CYLINDER_KIT_J3 | 1 | ||
| 8 | T2501HJ30060N | HOSE, ABS TO REAR CALIPER_KIT_J3 | 1 | ||
| 9 | T2001CKW0040N | CALIPER ASSY, REAR BRAKE RH | 1 | ||
| 10 | T2001EKE0021N | REAR MASTER CYL ASSY (DIA 12) | 1 | ||
| 11 | TSF0102271 | SCREW HEX FL M6X1X18X8.8 | 2 | ||
| 12 | T25010KE0030N | RESERVOIR ABS (J101) | 1 | ||
| 13 | T2501EJ30030N | HOSE, RESERVOIR_J3 | 1 | ||
| 14 | SF0401213 | Washer Plain M6x13x1 | 1 | ||
| 15 | T1501AKE2050E | CABLE STRAP 200MM | 4 | ||
| 16 | T20000KW0170N | TORSION RETURN SPRING, REAR BRAKE PEDAL | 1 | ||
| 17 | T20010J30010N | REAR BRAKE LEVER SUB ASSY_J3 | 1 | ||
| 18 | T20010KW0100N | PIN PIVOT, REAR BRAKE PEDAL | 1 | ||
| 19 | T25000KE0310N | LOCKING PIN | 1 | ||
| 20 | T2501EKW0020N | REAR MASTER CYL PRESSURE SWITCH KIT | 1 | ||
| 21 | T2001KKW0020N | REAR BRAKE PAD KIT | 1 | ||
| 22 | T2001KKW0040N | BOOT KIT | 1 | ||
| 23 | T2001KKW0010N | BLEEDER SCREW KIT | 1 | ||
| 24 | T2001KKW0030N | PAD PIN KIT | 1 | ||
| 25 | T1501AKW0070N | DOUBLE CABLE CLIP_REV0_L1_A2 | 2 | ||
| 26 | T20000Y50020N | BRAKE OIL RESERVOIR COVER | 1 |
